Deep learning reconstruction for lumbar spine MRI acceleration: a prospective study
European Radiology Experimental volume 8, Article number: 67 (2024)
Abstract
Background
We compared magnetic resonance imaging (MRI) turbo spin-echo images reconstructed using a deep learning technique (TSE-DL) with standard turbo spin-echo (TSE-SD) images of the lumbar spine regarding image quality and detection performance of common degenerative pathologies.
Methods
This prospective, single-center study included 31 patients (15 males and 16 females; aged 51 ± 16 years (mean ± standard deviation)) who underwent lumbar spine exams with both TSE-SD and TSE-DL acquisitions for degenerative spine diseases. Images were analyzed by two radiologists and assessed for qualitative image quality using a 4-point Likert scale, quantitative signal-to-noise ratio (SNR) of anatomic landmarks, and detection of common pathologies. Paired-sample t, Wilcoxon, and McNemar tests, unweighted/linearly weighted Cohen κ statistics, and intraclass correlation coefficients were used.
Results
Scan time for TSE-DL and TSE-SD protocols was 2:55 and 5:17 min:s, respectively. The overall image quality was either significantly higher for TSE-DL or not significantly different between TSE-SD and TSE-DL. TSE-DL demonstrated higher SNR and subject noise scores than TSE-SD. For pathology detection, the interreader agreement was substantial to almost perfect for TSE-DL, with κ values ranging from 0.61 to 1.00; the interprotocol agreement was almost perfect for both readers, with κ values ranging from 0.84 to 1.00. There was no significant difference in the diagnostic confidence or detection rate of common pathologies between the two sequences (p ≥ 0.081).
Conclusions
TSE-DL allowed for a 45% reduction in scan time over TSE-SD in lumbar spine MRI without compromising the overall image quality and showed comparable detection performance of common pathologies in the evaluation of degenerative lumbar spine changes.
Relevance statement
Deep learning-reconstructed lumbar spine MRI protocol enabled a 45% reduction in scan time compared with conventional reconstruction, with comparable image quality and detection performance of common degenerative pathologies.
Key points
• Lumbar spine MRI with deep learning reconstruction has broad application prospects.
• Deep learning reconstruction of lumbar spine MRI saved 45% scan time without compromising overall image quality.
• When compared with standard sequences, deep learning reconstruction showed similar detection performance of common degenerative lumbar spine pathologies.
Graphical Abstract
Background
Lumbar pain is a common chronic pain in clinical practice. Various factors contribute to the onset of the disease, and current research indicates that lumbar spine disease is the primary cause of low back pain [1]. Lumbar spine x-ray and computed tomography can show the bony structure of the lumbar spine, but the former does not show the lumbar intervertebral discs and the surrounding soft tissues while the latter shows them with relatively limited contrast resolution, and both of them imply ionizing radiation exposure for the patients. Magnetic resonance imaging (MRI) is widely used for routine examination of lumbar spine diseases due to the absence of ionizing radiation and high soft tissue contrast [2]. However, as lumbar MRI examination takes a relatively long time, patients with severe lumbar spine diseases may experience significant pain during the examination, resulting in body displacement and motion artifacts, which would impede diagnostic accuracy [3]. Research has focused on finding ways to shorten the examination time for the lumbar spine MRI while still meeting the image quality requirements for clinical diagnosis [4,5,6].
In recent years, with the rapid development of artificial intelligence, deep learning (DL)-based image enhancement techniques have been applied for MRI fast imaging [7,8,9]. This approach uses neural networks with many layers of processing units to learn complex patterns in large amounts of data [10, 11]. Unlike conventional fast acquisition methods which modify imaging parameters at the cost of reduced clarity and signal-to-noise ratio (SNR), DL-based techniques enable higher-quality reconstruction from undersampled k-space data by learning complex mappings between undersampled and fully-sampled data [12]. However, despite its advantages, we are concerned about whether the quality of the images obtained with DL reconstruction is consistent with that of standard scanning protocols and whether the post-processed images truly reflect the nature of abnormities.
In this prospective study, we aimed to compare the image quality and detection performance of common degenerative pathologies in lumbar spine MRI reconstructed using a DL technique with those obtained with standard protocols.
Methods
Participants
The study was approved by the Ethics Committee of Shanghai Renji Hospital, China (Ethics No. LY2023-121-B). All subjects signed an informed consent form before the MRI examination. Patients suspected of having degenerative lumbar spine diseases who were scheduled for lumbar spine MRI from October to November 2023 were prospectively enrolled. The exclusion criteria were (1) a history of lumbar spine surgery or implantation of metallic foreign bodies, (2) those who suffered from claustrophobia, (3) those who had contraindications to MRI examination, and (4) those who had intolerable pain in the lumbar region and could not lie down for a long time.
Imaging protocol
Standard and accelerated lumbar spine MRI examinations were performed on all patients using a Siemens 3-T MRI unit (MAGNETOM Prisma, Siemens Healthcare, Erlangen, Germany). Standard turbo spin-echo (TSE-SD) protocol included sagittal T1-weighted and T2-weighted imaging with no acceleration, transverse T2-weighted imaging with no acceleration, and sagittal fat-suppressed T2-weighted imaging with an acceleration factor of 2 and a number of excitations of 2. Accelerated turbo spin-echo protocol with DL reconstruction (TSE-DL) included the same sequences with an acceleration factor of 2 for non-fat-suppressed imaging and a number of excitations of only 1 for fat-suppressed T2-weighted imaging. The undersampled scans were reconstructed by a dedicated software (SubtleMR V2, Subtle Medical, Menlo Park, USA) using DL algorithms to obtain the processed TSE-DL images. SubtleMR is a US Food and Drug Administration–FDA-cleared and European Conformity–CE-marked software utilizing a deep back-projection network for DL reconstruction of MRI. SubtleMR has been trained and validated on a multicenter dataset of over a million MRI image pairs from various vendors and modalities [13]. It can be utilized for different contrast images including T1-weighted and T2-weighted imaging. Details on the dedicated software and the DL algorithm are summarized in Supplementary Material 1: Appendix 1. The specific parameters of TSE-SD and TSE-DL protocols are detailed in Table 1.
Image analysis
All images were randomly sorted, and image quality and diagnosis evaluation of TSE-SD images and TSE-DL images were performed independently by two radiologists with more than 10 years of experience in lumbar spine imaging. Before performing the actual image analysis, both readers underwent a training session that encompassed datasets not part of the current study. This training was designed to acquaint the readers with the Likert scale classification system detailed in the following paragraph. The readers were blinded to MRI protocol type, clinical information, and radiologic reports. All markers that could potentially identify patients or sequences were removed. To minimize recall bias, interpretations of the TSE-SD and TSE-DL images for each patient were conducted in two sessions separated by 4 weeks. Each reconstruction type and patient order were randomized in the sessions. Randomization was achieved by sorting the datasets using random numbers.
Qualitative image analysis was performed on each series with the use of a 4-point Likert scale for the following items: sharpness of anatomic structures (intervertebral discs, vertebrae, cerebrospinal fluid, intervertebral foramina, spinous processes, small joints, and nerve roots), artifacts, noise, overall image quality, and diagnostic confidence. For sharpness, overall image quality, and diagnostic confidence, the scoring system was as follows: 1, poor; 2, fair; 3, good; and 4, excellent. Artifacts and noise were rated as follows: 1, severe; 2, moderate; 3, mild; and 4, none. Examples of the application of the 4-point Likert scale are shown in Supplemental Fig. S1.
For quantitative image analysis, we placed round or oval regions of interest and measured the SNR on sagittal images for the L1–L5 vertebrae, L1–L5 intervertebral discs, psoas major muscles, cerebrospinal fluid, and fat and on transverse images for the right and left nerve roots, right and left psoas major muscles, L3/4 intervertebral discs, cerebrospinal fluid, and fat. All regions of interest were aligned with the center of the anatomy, while excluding the boundary region. The average size was 204.9 mm2 (range 202–206.3 mm2) for the vertebrae, 24.7 mm2 (21.4–27.6 mm2) for the intervertebral discs, 184.8 mm2 (182.4–187.2 mm2) for the psoas major muscles, 25 mm2 (23.4–26.1 mm2) for the cerebrospinal fluid, and 29.8 mm2 (27.6–30.8 mm2) for the fat on sagittal images and 1.1 mm2 (1.0–1.3 mm2) for the nerve roots, 70.2 mm2 (68.4–71.8 mm2) for the psoas major muscles, 325.3 mm2 (324.1–326.7 mm2) for the L3/4 intervertebral discs, 9.2 mm2 (6.2–10.8 mm2) for the cerebrospinal fluid, and 25.2 mm2 (23.4–26.8 mm2) for the fat on transverse images. The illustration of the region of interest placement is presented in Supplemental Fig. S2. The following formula was used to calculate the SNR:
Furthermore, the readers recorded the presence or absence of the following pathologies on a vertebral level: spinal stenosis, foraminal stenosis, intervertebral disc degeneration, disc bulge, disc herniation, facet synovial cyst, Modic changes, and Schmorl nodes.
Statistical methods
Continuous variables were tested for normality using the Shapiro-Wilk test and reported as means ± standard deviations or medians and interquartile ranges. Categorical variables were reported as numbers and percentages. The paired-sample t test or Wilcoxon test were used to determine the differences between the groups. Interreader agreement was assessed by using the unweighted Cohen κ statistics for binary variables, linearly weighted Cohen κ statistics for ordinal variables, and intraclass correlation coefficients (two-way model, absolute agreement, and single measures) for continuous variables, as well as for the interprotocol agreement. The agreements were interpreted as follows: 0–0.20, poor agreement; 0.21–0.40, fair agreement; 0.41–0.60, moderate agreement; 0.61–0.80, substantial agreement; and 0.81–1.00, almost perfect agreement [14]. The McNemar test was used to compare the differences in detecting major pathologies by TSE-SD and TSE-DL. A two-sided p < 0.05 was considered statistically significant. For image quality comparison, the significance level was reduced to an α-adjusted p-level of 0.05/2 according to Bonferroni correction, where 2 is the number of tests conducted for each aspect of image quality [15]. Statistical analyses were performed using SPSS version 21 (IBM Corp, Armonk, NY, USA).
Results
Study participants
Two patients who were unable to adhere to the examination due to back pain were excluded, and finally, a total of 31 patients were enrolled (15 males and 16 females; mean age 51 ± 16 years). All enrolled patients completed the examination with complete TSE-SD and TSE-DL sequences.
Scan time
The total scan time for TSE-SD and TSE-DL protocols were 317 s (5:17 min:s) and 175 s (2:55 min:s), respectively, with a scan time saving of 45%.
Image quality
Qualitative analysis
Results of the qualitative analysis are shown in Table 2 and Supplemental Tables S1, S2 and S3. Reader 1 reported better image sharpness for TSE-DL compared with TSD-SD in non-fat-suppressed sequences (p ≤ 0.022) (Fig. 1), whereas reader 2 found no evidence of a significant difference in sharpness (p ≥ 0.087). Both readers reported more artifacts on TSE-DL fat-suppressed T2-weighted images than TSD-SD images (p < 0.001 for reader 1 and p = 0.001 for reader 2) (Fig. 2). No evidence of a significant difference in artifacts was found between TSE-DL and TSE-SD in other non-fat-suppressed sequences (p ≥ 0.084). Noise was reduced in TSE-DL compared with TSD-SD in all sequences (Fig. 1), although no significant difference was observed in transverse T2-weighted images for reader 2 after Bonferroni correction (p = 0.044). The overall image quality was higher for TSE-DL in non-fat-suppressed sequences, although significant differences were only observed in sagittal T1-weighted images (p = 0.003 for reader 1 and p = 0.008 for reader 2) and transverse T2-weighted images (p = 0.022 for reader 1). In terms of diagnostic confidence, no significant difference was observed between TSE-DL and TSE-SD (p ≥ 0.081 for both readers). Interreader agreement for the qualitative image quality analysis was fair to substantial (weighted κ = 0.26–0.73), except for the evaluation of artifacts on sagittal T2-weighted images (weighted κ = 0.13, poor agreement) (Table 2 and Supplemental Tables S1, S2 and S3).
Quantitative analysis
For each anatomy evaluated, TSE-DL images showed better SNR compared with TSE-SD images on each sequence, although reader 2 reported no significant differences in the L1/2 intervertebral disc and fat on sagittal fat-suppressed T2-weighted images after Bonferroni correction (p = 0.039 and p = 0.048, respectively) (Table 3 and Supplemental Tables S4, S5 and S6). Interreader agreement for SNR measurement of each anatomy was moderate to almost perfect (intraclass correlation coefficient range 0.54–0.94) (Table 3 and Supplemental Tables S4, S5 and S6).
Detection performance of common degenerative pathologies
For detecting common pathologies, the κ values of the interprotocol intrareader agreement ranged from 0.84 to 1 for reader 1 and from 0.87 to 1.00 for reader 2, both indicating almost perfect agreement (Table 4). For each protocol, the intraprotocol interreader agreement was moderate to almost perfect for TSE-SD with κ values ranging from 0.58 to 1.00 and substantial to almost perfect for TSE-DL with κ values ranging from 0.61 to 1.00 (Table 4).
Detection rates of major pathologies by TSE-SD and TSE-DL are shown in Table 5, with no evidence of significantly higher detection rates by TSE-SD compared with TSE-DL (p ≥ 0.219). Figures 3 and 4 show cases with lumbar disc herniation and Schmorl nodes, respectively, both of which were well represented and could be diagnosed on TSE-SD and TSE-DL images.
Discussion
We prospectively investigated the application of DL reconstruction in lumbar spine MRI scanning and evaluated the difference between TSE-SD and TSE-DL in terms of image quality and detection performance of common degenerative pathologies. Our results showed that the application of TSE-DL with an approximate 45% reduction in scan time could improve or at least maintain the overall image quality and was clinically feasible for the detection of common degenerative pathologies in lumbar spine MRI. Compared with TSE-SD, TSE-DL had higher SNR and was not significantly different in diagnostic confidence. With regard to the detection of common degenerative pathologies, TSE-DL showed substantial to almost perfect interreader and interprotocol reproducibility and exhibited detection rates comparable to TSE-SD.
DL reconstruction for MRI has recently gained increasing attention and shown promising results in providing a balance between scan efficiency and image quality. Sebastain et al. [16] decreased about 60% scan time by reducing the number of acquisitions in three-plane T2-weighted TSE imaging in the prostate and reported improved image quality for DL reconstruction. Lee et al. [17] found that fourfold parallel accelerated fat-suppressed T2-weighted TSE MRI with DL reconstruction had comparable subject image quality compared with twofold parallel accelerated MRI without DL reconstruction in the knee, with a scan time reduction of 47%. However, previous studies have been conducted on a limited number of sequences, whereas in clinical settings, the MRI protocol usually consists of multiple sequences. In this study, the TSE-DL protocol used for lumbar spine MRI included sagittal T1-weighted and T2-weighted imaging and transverse T2-weighted imaging with an acceleration factor of 2, and sagittal fat-suppressed T2-weighted imaging with a number of excitations of only 1, while other parameters remained consistent with the TSE-SD protocol.
The total scan time with TSE-DL was 2:55 min:s, enabling a 45% reduction compared to TSE-SD. Reducing scan time not only alleviates patient discomfort during prolonged examinations but also enables more efficient resource allocation, ultimately leading to improved patient throughput.
According to the subjective evaluation of two readers, the noise of TSE-DL was lower than that of TSE-SD. Measurement of image SNR by two readers also indicated that TSE-DL had improved SNR compared with TSE-SD. These results are consistent with previous studies [13, 18, 19]. For instance, Bash et al. [13] enrolled 61 patients undergoing lumbar spine MRI and found that the SNR of fast DL imaging sequences was better than that of standard sequences. We also found that TSE-DL was comparable to TSE-SD in sharpness of anatomic structures. Similar results were reported by Yasaka et al. [20], who showed better results for DL-reconstructed cervical spine sagittal T2-weighted MRI compared with standard MRI for the depiction of anatomic structures except for disc and foramina by one reader. In terms of artifacts, there was no evidence of a significant difference in non-fat-suppressed sequences between the two protocols, while TSE-DL obtained a lower score than TSE-SD in sagittal fat-suppressed T2-weighted images. The common artifacts seen on TSE-DL images were residual aliasing artifacts, appearing as ghosts inside or outside the object of interest [21]. Almansour et al. [5] found that the residual aliasing artifact was one of the main sources of artifacts for spine MRI due to undersampling associated with accelerated acquisition, similar to our observations. As a result, the subjective artifact score of TSE-DL was lower than that of TSE-SD for sagittal fat-suppressed T2-weighted images. Nevertheless, diagnostic confidence of TSE-DL did not appear to be much influenced by the low artifact score, with no evidence of a significant difference with TSE-SD. Last, TSE-DL yielded a comparable overall image quality to TSE-SD, consistent with previous studies [22, 23]. Our results indicated that DL reconstruction for the whole lumbar spine MRI protocol at a scan time reduction of 45% would not reduce the overall image quality. Regarding the detection performance of common degenerative pathologies, we observed for TSE-DL a similar detection rate to TSE-SD. Interprotocol and interreader agreement were substantial to almost perfect. These results are in line with previous studies on spine MRI [5, 6] and hand and wrist MRI [24].
There are several limitations in our study. First, this experiment was done on a single MRI scanner in a single center with a small sample size. Although some statistical significance was achieved, it is necessary to expand the sample size and try it on other scanners and field strengths to observe whether the same results can be obtained. Second, no preliminary calculation of the sample size was done, so that no distinction among primary, secondary, and exploratory endpoints was defined, and the correction of the p-value threshold for statistical significance was done a posteriori. Third, only two radiologists participated in the reading sessions. More radiologists with different experience levels are also needed to generalize our results. Fourth, only a limited number of degenerative disorders were included, and patients with a history of lumbar spine surgery or metal implants were excluded. Some other lumbar spine disorders such as vertebral hemangiomas, vertebral tumors, masses inside or compressing the spinal cord, and other complex conditions, as well as post-surgery and post-implant conditions, should be studied to evaluate the utility of DL reconstruction in the real clinical setting. Fifth, the data analysis conducted in this study was limited to the evaluation of image quality, interreader or interprotocol agreement, and detection rate of common pathologies. However, no noninferiority or equivalence statistical testing was performed between TSE-DL and TSE-SD in terms of diagnostic test comparison. Therefore, our findings should be interpreted with caution. Finally, this experiment was conducted on non-contrast-enhanced lumbar spine MRI sequences. Whether the contrast agent would affect the measurement results still remains unclear and warrants further studies.
In conclusion, the TSE-DL protocol with a 45% reduction in scan time showed similar overall image quality in lumbar spine MRI when compared to TSE-SD for degenerative lumbar spine diseases. Application of TSE-DL is clinically feasible for detecting common degenerative abnormalities, with comparable diagnostic confidence and detection rate to TSE-SD. Future studies are warranted to determine the diagnostic equivalence between TSE-DL and TSE-SD with a large number of participants and readers. Moreover, the utility of DL reconstruction of lumbar spine MRI in a real clinical situation with other types of abnormities, various patient conditions, and potential application of contrast medium should be studied.
Availability of data and materials
The datasets used or analyzed during the current study are available from the corresponding author upon reasonable request.
Abbreviations
- DL:
-
Deep learning
- MRI:
-
Magnetic resonance imaging
- SNR:
-
Signal-to-noise ratio
- TSE-DL:
-
Turbo spin-echo with DL reconstruction
- TSE-SD:
-
Standard turbo spin-echo
References
Violante FS, Mattioli S, Bonfiglioli R (2015) Low-back pain. Handb Clin Neurol 131:397–410. https://doi.org/10.1016/B978-0-444-62627-1.00020-2
Beattie PF, Meyers SP (1998) Magnetic resonance imaging in low back pain: general principles and clinical issues. Phys Ther 78:738–753. https://doi.org/10.1093/ptj/78.7.738
Taber KH, Herrick RC, Weathers SW, Kumar AJ, Schomer DF, Hayman LA (1998) Pitfalls and artifacts encountered in clinical MR imaging of the spine. Radiographics 18:1499–1521. https://doi.org/10.1148/radiographics.18.6.9821197
Bratke G, Rau R, Weiss K et al (2019) Accelerated MRI of the lumbar spine using compressed sensing: quality and efficiency. J Magn Reson Imaging 49:e164–e175. https://doi.org/10.1002/jmri.26526
Almansour H, Herrmann J, Gassenmaier S et al (2023) Deep learning reconstruction for accelerated spine MRI: prospective analysis of interchangeability. Radiology 306:e212922. https://doi.org/10.1148/radiol.212922
Yoo H, Yoo RE, Choi SH et al (2023) Deep learning-based reconstruction for acceleration of lumbar spine MRI: a prospective comparison with standard MRI. Eur Radiol 33:8656–8668. https://doi.org/10.1007/s00330-023-09918-0
Bash S, Wang L, Airriess C et al (2021) Deep learning enables 60% accelerated volumetric brain MRI while preserving quantitative performance: a prospective, multicenter, multireader trial. AJNR Am J Neuroradiol 42:2130–2137. https://doi.org/10.3174/ajnr.A7358
Rudie JD, Gleason T, Barkovich MJ et al (2022) Clinical assessment of deep learning-based super-resolution for 3D volumetric brain MRI. Radiol Artif Intell 4:e210059. https://doi.org/10.1148/ryai.210059
Lundervold AS, Lundervold A (2019) An overview of deep learning in medical imaging focusing on MRI. Z Med Phys 29:102–127. https://doi.org/10.1016/j.zemedi.2018.11.002
Lecun Y, Bengio Y, Hinton G (2015) Deep learning. Nature 521:436–444. https://doi.org/10.1038/nature14539
Tian C, Xu Y, Li Z, Zuo W, Fei L, Liu H (2020) Attention-guided CNN for image denoising. Neural Netw 124:117–129. https://doi.org/10.1016/j.neunet.2019.12.024
Zaharchuk G, Gong E, Wintermark M, Rubin D, Langlotz CP (2018) Deep learning in neuroradiology. AJNR Am J Neuroradiol 39:1776–1784. https://doi.org/10.3174/ajnr.A5543
Bash S, Johnson B, Gibbs W, Zhang T, Shankaranarayanan A, Tanenbaum LN (2022) Deep learning image processing enables 40% faster spinal MR scans which match or exceed quality of standard of care: a prospective multicenter multireader study. Clin Neuroradiol 32:197–203. https://doi.org/10.1007/s00062-021-01121-2
Landis JR, Koch GG (1977) The measurement of observer agreement for categorical data. Biometrics 33:159–174. https://doi.org/10.2307/2529310
Johnson PM, Lin DJ, Zbontar J et al (2023) Deep learning reconstruction enables prospectively accelerated clinical knee MRI. Radiology 307:e220425. https://doi.org/10.1148/radiol.220425
Gassenmaier S, Afat S, Nickel MD et al (2021) Accelerated T2-weighted TSE imaging of the prostate using deep learning image reconstruction: a prospective comparison with standard T2-weighted TSE imaging. Cancers 13:3593. https://doi.org/10.3390/cancers13143593
Lee SM, Kim M, Park C et al (2024) Deep learning-reconstructed parallel accelerated imaging for knee MRI. Curr Med Imaging 20:e240523217293. https://doi.org/10.2174/1573405620666230524151816
Sun S, Tan ET, Mintz DN et al (2022) Evaluation of deep learning reconstructed high-resolution 3D lumbar spine MRI. Eur Radiol 32:6167–6177. https://doi.org/10.1007/s00330-022-08708-4
Kim E, Cho HH, Cho SH et al (2022) Accelerated synthetic MRI with deep learning-based reconstruction for pediatric neuroimaging. AJNR Am J Neuroradiol 43:1653–1659. https://doi.org/10.3174/ajnr.A7664
Yasaka K, Tanishima T, Ohtake Y et al (2022) Deep learning reconstruction for 1.5 T cervical spine MRI: effect on interobserver agreement in the evaluation of degenerative changes. Eur Radiol 32:6118–6125. https://doi.org/10.1007/s00330-022-08729-z
Deshmane A, Gulani V, Griswold MA, Seiberlich N (2012) Parallel MR imaging. J Magn Reson Imaging 36:55–72. https://doi.org/10.1002/jmri.23639
Bischoff LM, Peeters JM, Weinhold L et al (2023) Deep learning super-resolution reconstruction for fast and motion-robust T2-weighted prostate MRI. Radiology 308:e230427. https://doi.org/10.1148/radiol.230427
Dratsch T, Siedek F, Zaske C et al (2023) Reconstruction of shoulder MRI using deep learning and compressed sensing: a validation study on healthy volunteers. Eur Radiol Exp 7:66. https://doi.org/10.1186/s41747-023-00377-2
Herrmann J, Gassenmaier S, Keller G et al (2023) Deep learning MRI reconstruction for accelerating turbo spin echo hand and wrist imaging: a comparison of image quality, visualization of anatomy, and detection of common pathologies with standard imaging. Acad Radiol 30:2606–2615. https://doi.org/10.1016/j.acra.2022.12.042
Funding
This study was supported by a grant from Renji Hospital (RJKY23-004) and the Leading Talent of Shanghai Municipal Health Commission (2022LJ023).
Author information
Authors and Affiliations
Contributions
HT: conceptualization, methodology, formal analysis, investigation, data curation, writing—original draft, and writing—review and editing. MH: conceptualization, methodology, data curation, literature research, investigation, and writing—review and editing. LY: methodology and writing—review and editing. YS: technical support. MC: investigation and formal analysis. LX: technical support. YZ: investigation, formal analysis, and writing—review and editing. SS: data curation, methodology, investigation, supervision, and writing—review and editing. All authors read and approved the final manuscript.
Corresponding authors
Ethics declarations
Ethics approval and consent to participate
The study was approved by the Ethics Committee of Shanghai Renji Hospital (Ethics No. LY2023-121-B), and all participants gave written informed consent.
Consent for publication
All participants provided written informed consent.
Competing interests
YS is an employee of Siemens Healthineers. LX is an employee of Subtle Medical. The other authors declare that they have no competing interests.
